Optical ethernet adaptor/100M

Optical ethernet adaptor/1000M Optical Ethernet adapter OFS Series Optical Ethernet adapter is designed to operate at 100Mbps(1000Mbps) and to provide a network throughput of 200Mbps (2000Mbps) in full-duplex mode. It offers a range of options, such as fiber / connector type and operating wavelength / reach, to meet the requirement of various applications. The Optical Ethernet adapter also supports IEEE802.3x Flow Control Enhancements. Its optical transceiver is optional with different SFP module Features Optical transceiver optional with different SFP or 1x9 module Plug and Play installation Support Flow Control enabled with full duplex operation PCI Bus Master direct memory access for high throughput and low CPU utilization Two LED indicators: Link/Act, Power Drivers for all leading Network Operating Systems Standard Protocol 100M Optical Ethernet adapter IEEE 802.3u 100Base-FX / IEEE 802.3ah 100Base-LX10 / -BX10 Ethernet standard. 1000M Optical Ethernet adapter IEEE 802.3z 1000Base-SX / 1000Base-LX Ethernet standard. IEEE 802.3x Flow Control IEEE 802.1q/ VLAN Tagging supported GVRP VLAN IEEE 802.1p. priority class of service Compliant with ACPI specification. PCI 2.2 or PCI-Estandard Optical Interface SFP module: Optical Ethernet 1000Base-SX/ 1000Base-LX SFP Optical transceiver module 1x9 module Single single-mode fiber, dual wavelength 1310nm / 1550nm, single SC/PC connector, 20/40 km reach Dual single-mode fibers, single wavelength 1310nm or 1550nm, dual SC/PC connectors, 20/40/60 km reach Dual multimode fibers, single wavelength: 1310nm, dual SC/PC connectors, 2 km reach ModelProduct descriptionOFS-N101 100M SFP Port Optical Ethernet adapter PCI 2.2OFS-N102M 100M multimode Optical Ethernet adapter PCI 2.2OFS-N102S 100M singlemode Optical Ethernet adapter PCI 2.2OFS-N201 1000M SFP Port Optical Ethernet adapter PCI 2.2OFS-N202M 1000M multimode Optical Ethernet adapter PCI -EOFS-N202S 1000M singlemode Optical Ethernet adapter PCI -E
